Notes:Our company continues to research and improve product specifications and design details. If the above specifications are subject to change, please refer to the actual product!
Main Functions and Features of the Equipment (Photos for Reference Only)
Serial number
Name
Reference picture
Remark
1
Human
computer
interface
Main function: Equipment start/stop, function selection,parameter configuration, warning notifications, and otherfunctions. Featuring a streamlined touch-screen interfacethe system requires only minimal training to operate.
2
Pre-milling
The edge of the panel is cut and trimmed, make the edgeof the panel is more smooth and flat, without burr. Makethe edge band tape and panel fit more tightly, after theedge of the glue line is smaller.
3
PUR gluepot
The no-clean PUR two-color glue pot can reduceproblems such as cleaning the glue pot and wasting glue.The glue line is small, and PUR glue is highly sticky.
4
Top glue pot
The glue pot heats up rapidly and delivers excellentedge-banding results for materials such as PVC andhigh-gloss door panels.it enables seamless,glue-line-free" edge banding, while its pneumatic designensures simpler operation.
5
Five-wheel pressing
Multi-point contact ensures tight, firm pressing, resulting in a stronger bond between the edge banding and the board material.
6
Synchronous Servo Tape Feeding
Through closed-loop control of position, speed, and torque, the servo motor precisely regulates the feed rate of the edge banding material; the margin of error is significantly reduced to the millimeter level, and stability is maintained even at high feed speeds (e.g., 15–28 m/min).
7
Trimming Mechanism
Edge trimming involves cutting away excess edge banding from the top and bottom edges of a panel to ensure it sits perfectly flush with the panel's height, thereby achieving a more refined finish and a superior tactile feel. Furthermore, its innovative dust collection design enables highly precise chip removal and dust extraction.
8
Scraping
On the top and bottom of the edge sealing belt after trimming, scrape out the α Angle circular edge, make the edge sealing effect is more exquisite.
9
Double rails end cutting
Trim the excess edge banding from the front edge of the banded panel to ensure the banding is flush with the board.
10
Corner rounding
The four corners of the edge-banded panels undergo chamfering and rounding, resulting in a more refined and smooth finish. Additionally, the integration of a new dust extraction system effectively removes excess waste, thereby extending the service life of the equipment.
11
Double buffing
The panel after sealing the edge is polished to make the top and bottom sides of the edge sealing belt more smooth and beautiful.
Noted：Our company continues to research and improve product specifications and design details. If the above specifications are subject to change, please refer to the actual product!
